ROYAL – 7016 E7016 Low Hydrogen Type Electrodes

A medium heavy coated all position hydrogen controlled electrode for The welding of medium high tensile structural steel such as Carbon steels upto 0.4% C, Manganese steel upto 2.0% Mn, Silicon steel upto 0.5% Cr, Chrome Nickel steels and other heat treated steels where matching of base metal and weld metal is not necessary.
Sizes(mm) we are dealing in:-
2.50 x 350
3.15 x 450
4.00 x 450
5.00 x 450

ROYAL – 7016 (W) E7016 Low Hydrogen Type Electrodes

A medium heavy coated all position hydrogen controlled electrode for The welding of medium high tensile structural steel such as Carbon steels upto 0.4% C, Manganese steel upto 2.0% Mn, Silicon steel upto 0.5% Cr, Chrome Nickel steels and other heat treated steels where matching of base metal and weld metal is not necessary.
Sizes(mm) we are dealing in:-
2.50 x 350
3.15 x 450
4.00 x 450
5.00 x 450

ROYAL THERM E7018 Low Hydrogen Type Electrodes

This is a basic heavy coated low hydrogen iron powder type electrode with excellent weld characteristic. very smooth arc, medium penetration and low spatter, easy to remove slag. the weld metal is ductile and crack resistant and is of radiographic quality. it is easy to operate in all position and deposition efficiency is approximately 115%. ( PLEASE KEEP DRY )
Sizes(mm) we are dealing in:-
2.50 x 350
3.15 x 450
4.00 x 450
5.00 x 450

ROYAL THERM H4R Low Hydrogen Type Electrodes

E 7018 H4 R

The low hydrogen controlled, vacuum packed, basic coated electrodes which is welder friendly and is recommended for welding of mild steel, medium carbon, steel, high strength steel, cast steel and problematic steels. The electrodes is vacuum packed and hence does not require expensive redrying at 300°C for 2 hours or a higher temperature. The weld metal is clean and has lowest level of impurities with has much longer life than the weld metal usually deposited with other E 7016 or E 7018 class of electrodes. Deposited weld metal met X-ray radiographic quality standards.
Sizes(mm) we are dealing in:-
2.50 x 350
3.15 x 450
4.00 x 450
5.00 x 450

ROYAL THERM 2H (SPL) E 7018-NACE electrode

A heavy coated iron powder type all position electrode for welding of high tensile, heavy sections, structural steel and restrained joints in high tensile steels. It gives smooth arc, medium penetration and detach the slag easily in a Vee grove joint. The electrode is used for critical welding and gives excellent welding characteristics, the weld metal contains 1.20% Mn and controlled Sulphur as well as Hydrogen which is extremely resistant to cold and hot.
Sizes(mm) we are dealing in:-
2.50 x 350
3.15 x 450
4.00 x 450
5.00 x 450

ROYAL – 724 E7024 Low Hydrogen Type Electrodes

A heavy coated iron powder type electrode with a deposition efficiency of approximately 140%. It is touch welding electrode with high deposition rate for flat and horizontal position. The electrode is easy to manipulate and gives smooth arc with radiographic quality of welds. It can be used at high current and gives high welding productivity.
Sizes(mm) we are dealing in:-
2.50 x 350
3.15 x 450
4.00 x 450
5.00 x 450

ROYAL THERM. SPL H4R E 7018-1 H4R Low Hydrogen Type Electrodes

The hydrogen controlled, vacuum packed, basic coated electrodes which is welder friendly and is recommended for welding of mild steel, medium carbon, steel, high strength steel, cast steel and problematic steels. The electrodes is vacuum packed and hence does not require expensive redrying at 250oC for 2 hours or a higher temperature. The weld metal is clean and has lowest level of impurities with has much longer life than the weld metal usually deposited with other E 7016 or E 7018 class of electrodes. Deposited weld metal met X-ray radiographic quality standards.
Sizes(mm) we are dealing in:-
2.50 x 350
3.15 x 450
4.00 x 450
5.00 x 450
